Primary Side Component Location
Figure 86. Primary Side Processor/Memory Module Component Location
208
A
B
H
G
A
Processor 1
B
Processor 3
C
Memory board release mechanism
D
Memory board 1
E
3.3 V DC-to-DC converter 1
F
Power pod 3
G
Power pod cable
H
Power pod 1
C
F
Intel® SR870BN4 Server System Product Guide
D
E
OM12919
