Part II: Service Technician's Guide

5 Working Inside the System
6 Servicing the I/O Bay
7 Servicing the Processor/Memory Module
8 Servicing the Peripheral Bay
9 Servicing the Power Supply Bay
10 Servicing the Chassis
11 Technical Reference
A POST Error Codes and Messages
B Equipment Log and Configuration Worksheet
C Warnings
D INI File Format
E SDRViewer Splash Screen File Format
F SELViewer Splash Screen File Format
G Glossary
H Troubleshooting
WARNING
Only a QUALIFIED SERVICE TECHNICIAN is authorized to remove
the server covers and to access any of the components inside the server.
Before removing the covers, see "Safety: Before Top Cover or Module
Removal" on page 179 and "Warnings and Cautions" on page 179.
WARNING
Anchor the equipment rack: The equipment rack must be anchored to
an unmovable support to prevent it from falling over when one or more
servers are extended in front of it on slides. The anchors must be able to
withstand a force of up to 113 kg (250 lbs.). You must also consider the
weight of any other device installed in the rack. A crush hazard exists
which could cause serious injury to personnel should the rack tilt
forward.
Main AC power disconnects: An AC power disconnect for the entire
rack unit must be installed. This main disconnect must be readily
accessible, and it must be labeled as controlling power to the entire unit,
not just to the server(s).
Intel® SR870BN4 Server System Product Guide 175
