Text Command Format

Text commands do not support the bridging and sequence number fields present in the hex-ASCII
commands, are case sensitive, and are preceded by a prefix consisting of the string "SYS".
Examples
Hex-ASCII command example (IPMI Reset Watchdog Cmd):
[18 00 22]<CR>
[1C 00 22 00]<CR-LF>
Text command example:
[SYS TMODE]<CR>
[OK TMODE]<CR-LF>

Terminal Mode IPMI Message Bridging

Terminal mode supports the ability to bridge IPMI messages to another interface when binary
hex-ASCII IPMI commands are used. The message bridge is determined by the following: the
bridge field, whether the message is a request or a response, the message direction with respect to
the BMC and the LUN. Table 28 lists the supported BMC combinations for IPMI message
bridging. Any other combinations are unsupported.
Note that IPMI messages to and from the system interface are transferred using the BMC SMS
(System Management Software) LUN, 10b, and with the bridge field set to 00b.
Table 28. Supported BMC Combinations for IPMI Message Bridging
Bridge Request/
Field Response
00b Request
00b Response
00b Request
00b Response
01b Response
152
Message
Direction (to BMC) LUN
In 00b,
01b,
11b
Out 00b,
01b,
11b
In 10b
Out 10b
Out Any
Message
Interpretation
Remote Console request to BMC functionality
Message is a request from the remote console to
the BMC
Response to Remote Console from BMC
functionality Message is a response to an earlier
request from the remote console to the BMC
Remote Console request to SMS Message is a
request from the remote console to SMS via the
Receive Message Queue
SMS Response to Remote Console Message is a
response to an earlier request from SMS
Response to earlier Bridged Request from Remote
Console Message is the asynchronous response
from an earlier bridged request that was
encapsulated in a Send Message command issued
to the BMC by the remote console
