Individual SDRs of each type have their own display name format, as shown in the table below.
Table 23. SDR Type Name Format
SDR Type [Hex]
Type 1
Type 2
Type 8
Type 9
Type 10
Type 11
Type 12
Type 13
Type 14
Type C0
The SDR type displays names in a single format: [SDR type hex] – [SDR type text] ([count of
SDRs of this type]).
Under certain circumstances, the type C0 format does not follow the rules defined above. When all
the characters of the data portion of the record are printable ASCII characters, the data area is
considered to be a string and is used for the display name instead of the format defined in the table.
Close Button
This button closes the current SDR window and returns the user to the SDR selection screen.
Previous Button
This button closes the current SDR window and displays the previous SDR record, the previous
record must be of the same type as the current record. If this is the first SDR record in the SDR
type branch, this button is disabled.
Next Button
This button closes the current popup window and displays the next SDR record in the SDR tree, the
next record must be of the same type as the current record. If this is the last SDR record in the SDR
type branch, this button is disabled.
Save To File Button
This button allows the user to save the current SDRs to a file. If the save fails because the file
cannot be created, the following message is displayed:
Unable to create save file
If an error occurs while writing information to the file, the following message is displayed:
Error saving SDRs to the file
Open File Button
This button allows the user to open a currently saved SDR file. Upon selecting this option, all
currently loaded SDRs are deleted and only the SDR loaded from the file are displayed. If the file
is not a valid SDR file, an error message is displayed.
130
[sensor type HEX] – [sensor type text] ([ID string]) sensor #[sensor number]
[sensor type HEX] – [sensor type text] ([ID string]) sensor #[sensor number]
[sensor type HEX] – [sensor type text] ([ID string])
[sensor type HEX] – [sensor type text] ([ID string])
[sensor type HEX] – [sensor type text] ([ID string])
[sensor type HEX] – [sensor type text] ([ID string])
[Entity ID HEX] – [entity ID text] ([ID string])
[sensor type HEX] – [sensor type text] ([ID string])
[sensor type HEX] – [sensor type text] ([ID string])
OEM SDR ([record ID])
Display Name Format
