LSI Logic MPT SCSI Setup Utility Version v1.00.04.00
Device Properties
SCSI Device Identifier
ID
0
1
~
6 ESG-SHV
7 53C1030
8
~
11
12 Maxtor
13
14
15
F1/Shift+1 =Help
Esc = Abort/Exit
The Device Properties Menu shows options of devices attached to the adapter. It is a large menu
and requires the use of the arrow keys to move fully to the left and fully down to see all
configuration options. There are "slide bars" (not shown above) to the right and on the bottom to
help define your location in the menu. The following list shows the available options for each
setting category:
MB/Sec 320
MT/Sec 0 or 5, 10, 20, 40, 80, 160
Data Width 16 or 8
Scan ID Yes or No
Scan Luns >0 Yes or No
Disconnect On or Off
SCSI Timeout <10>
Queue Tags On or Off
Format, Verify, and Restore Defaults are all functions. They are located on the far left of the menu,
but are shown below the other configuration options in the figure above. Format and Verify takes
the user to another menu, see Figure 17 and Figure 18 below. These menus give appropriate
warnings and allows the user the option of continuing with the function or canceling. Restore
Defaults function do not take the user to another menu and does not give the user the option to
cancel. If the user makes changes and then accidentally select the Restore Defaults function, all
changes will be discarded.
Intel® SR870BN4 Server System Product Guide
MB/ MT/ Data Scan Scan Luns Disconnect SCSI
Sec Sec Width ID
320 [160] [16] [Yes] [Yes]
Arrow Keys/H,J,K,L =Select Item
Home (I)/End (O) = Select Item
Figure 16. Device Properties
>0 Timeout Tags
[On] <10>
Format Verify Restore Defaults
<Format> <Verify> <Defaults>
+/- = Change [Item]
Enter = Execute [Item]
Queue
[On]
