Remote Keyboard Navigation; Local Keyboard Navigation - Intel SR870BN4 - Server Platform - 0 MB RAM Product Manual

user interface component will be a Java application. Running the remote SMU requires the use of
Intel Server Management.
NOTE
The local SMU application is available only in English.

Remote Keyboard Navigation

The remote SMU application requires a pointing device for operation; it does not support
accelerator keys. Other keys work as described in Table 19.
Table 19. Keyboard Support for Remote SMU Client
Key Function
<Enter> Pressing <Enter> when focus is on a button causes the action associated with that button
to occur.
<Tab> Moves focus to the next control in the tab order in the primary information pane.
<Shift><Tab> Moves focus to the previous control in the tab order.

Local Keyboard Navigation

The local SMU application provides keyboard support as follows:
Table 20. Keyboard Support for Local SMU Client
Key Function
<Enter>
If the cursor is in an edit box, the <Enter> key moves the cursor to the next selectable
control in the currently active pane. When the focus is on a task menu item, a task button, a
radio button, or a check box, pressing <Enter> selects the control. If the focus is on a
single-select control (combo box), pressing <Enter> has no effect.
<Tab> Moves focus to the next control in the tab order in the primary information pane.
<Up arrow> Moves the cursor to the previous selectable control in the currently active pane.
<Down arrow> Moves the cursor to the next selectable control in the currently active pane. (Same as the
<Tab> key.)
<Right Moves the cursor to the next selectable control in the currently active pane. (Same as the
arrow>
<Tab> key.)
<Left arrow> Moves the cursor to the previous selectable control in the currently active pane. (Same as
the <UP arrow> key.)
<F5> key If a horizontal scroll bar is in the active pane, pressing <F5> scrolls the display left.
<F6> key
If a horizontal scroll bar is in the active pane, pressing <F6> scrolls the display right.
<F7> key If a vertical scroll bar is in the active pane, pressing <F7> scrolls the display up.
<F8> key
If a vertical scroll bar is in the active pane, pressing <F8> scrolls the display down.
<F10> key Toggles the focus between the task pane and the primary information pane.
<ESC> key Displays the Exit dialog.
84 Intel® SR870BN4 Server System Product Guide
