Intel SR870BN4 - Server Platform - 0 MB RAM Product Manual page 279

Table 53. IA32 POST Codes (continued)
Code Value Module
0x0080 Mouse initialization of PS/2 mouse to program the IRQ level to edge triggered
or level triggered. The keyboard test has started. Clearing the output buffer
and checking for stuck keys. Issuing the keyboard reset command next.
0x0082 The keyboard controller interface test completed. Write the command byte
and initializing the circular buffer next.
0x0083 The command byte was written and global data initialization has completed.
Checking for a locked key next.
0x0084 Locked key checking is over. Identify ATAPI devices.
0x0089 The programming after Setup has completed. Displaying the power on screen
message next.
0x008B Init boot devices. Check for and reset mouse.
0x008C Npost adjustments to setup. Form E820 tables. Program SETUP-selected
chipset and Sup-IO parameters.
0x008D The Setup options are programmed. Resetting the hard disk controller.
0x008E OEM patches executed. Decompress INT13 module and init ATA & ATAPI
devices.
0x0093 Done with ATA & ATAPI init. Set RS-232 time out.
0x0095 Initializing the bus option ROMs from C800 next. SCSI opt ROM init.
0x0091 Configuring the hard disk drive controller. Initializing the CD ROM drive.
0x0092 -
0x0098 The adaptor ROM had control and has now returned control to BIOS POST.
Performing any required processing after the option ROM returned control.
Restoring INT10 vector.
0x0008 Debugging code. To be removed later.
0x0099 Configuring the timer data area and printer base address.
0x009B Returned after setting the RS-232 base address. Performing any required
initialization.
0x009E Initialization. Checking the extended keyboard, keyboard ID, and Num Lock
key next. Issuing the keyboard ID command.
0x00A2 Displaying any soft errors.
0x00A3 The soft error display has completed. Setting the keyboard typematic rate.
0x00A4 The keyboard typematic rate is set. Programming the memory wait
states next.
0x00A5 Memory wait state programming is over. Clearing the screen.
0x00A7 Performing any initialization required before passing control to the adaptor
ROM at E000 next.
0x00AE Setting up DMI structures.
0x0020 Talking to BMC.
0x0022 Talking to BMC.
0x00AC Uncompressing the DMI data and initializing DMI POST.
0x00AB Building the multiprocessor table.
Intel® SR870BN4 Server System Product Guide
Display
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
South
continued
279
