The following are true when using the above keys while running the local SMU application:
For single-select controls (combo boxes), the <up arrow> and <down arrow> keys can be
used to move through the items in the list. To move to a different control, the <Tab>, <left
arrow>, or <right arrow> keys are used.
For a set of grouped radio buttons from which only one can be selected, the <up arrow>,
<down arrow>, <left arrow>, and <right arrow> keys can be used to move
between buttons in the group. To move to a different control, the <Tab> key is used.
For edit box controls, the <left arrow> and <right arrow> keys can be used to move
the cursor within the edit box. To move to a different control, the <Tab>, <Enter>, <up
arrow>, or <down arrow> key are used.

About Box Information

The SMU includes an "About" item in the task pane when the task list is displayed. When
"About" is selected, a dialog box is displayed showing information about the SMU application
version. The information displayed consists of a set of four numbers, defined as follows:
The major feature release number
The minor platform or maintenance release number
The variant, used for things like different operating systems or languages
The build number
See the example below.
Intel® SR870BN4 Server System Product Guide
Figure 21. SMU Application About Box
85
