Page Destination Configuration
The Page Destination Configuration screen, shown below, is displayed when the user clicks Next
on the Destination Dial Strings screen. This screen allows the user to configure the settings for
each page destination that can be reached by sending a page through the serial/modem channel. Up
to eight page destinations can be configured; the Dial String column displays Not Configured
for any entry that has not been configured.
A page destination is comprised of:
A dial string to be used when a page is to be sent out
Retry information for the page
Configuration of the modem at the destination
The data shown for each page destination includes the dial string, call retries, flow control, baud
rate, parity, data bits, and stop bits for the destination modem. These settings are described in more
detail in the next section. This screen also displays general settings that apply to all alerts to be sent
as dial pages.
Intel® SR870BN4 Server System Product Guide
Figure 40. Page Destination Configuration
117
