Table 31. Terminal Mode Configuration
Byte Explanation
1 [7:6] - Reserved
[5] - Line Editing
0b = Disable
1b = Enable (Factory default)
[4] - Reserved
[3:2] - Delete control (only applies when line editing is enabled)
00b = BMC outputs a <DEL> character when <BKSP> or < DEL > is received
01b = BMC outputs a < BKSP >< SP >< BKSP > sequence when < BKSP > or < DEL > is
received (Factory default)
[1] - Echo control0b = No echo 1b = Echo (BMC echoes characters it receives) (Factory default)
[0] - Handshaking - BMC outputs a [SYS]<newline> after receiving each terminal mode IPMI
message and is ready to accept the next message
0b = Disable
1b = Enable (Factory default)
2 [7:4] - Output newline sequence (BMC to console). Selects what characters the BMC uses as the
<newline> sequence when the BMC writes a line to the console in Terminal Mode
0h = no termination sequence
1h = <CR-LF> (Factory default)
2h = <NULL>
3h = <CR>
4h = <LF-CR>
5h = <LF>
All other = reserved
[3:0] - Input newline sequence (Console to BMC). Selects what characters the console uses as the
<newline> sequence when writing to the BMC in Terminal Mode
0h = reserved
1h = <CR> (Factory default)
2h = <NULL>
All other = reserved
162 Intel® SR870BN4 Server System Product Guide
