Part I: User's Guide - Intel SR870BN4 - Server Platform - 0 MB RAM Product Manual

Part I: User's Guide

1 System Description
2 Board Set Description
3 Configuration Software and Utilities
4 Hot-swapping System Components
This manual consists of two parts:
User's Guide, beginning on page 13describes procedures that DO NOT REQUIRE internal
server access. The user does not need to be a qualified service technician to perform
procedures listed in the User's Guide.
Service Technician's Guide, beginning on page 175describes procedures that REQUIRE
internal server access. The user must be a qualified service configuration technician to perform
procedures listed in the Service Technician's Guide.
WARNING
Only a QUALIFIED SERVICE TECHNICIAN is authorized to remove
the server's covers and to access any of the components inside the server,
except as noted herein. Before removing top covers or modules, see
"Figure 58. Locating System Modules" on page 181 and "Warnings and
Cautions" on page 179.
WARNING
Anchor the equipment rack: The equipment rack must be anchored to an
unmovable support to prevent it from falling over when one or more
servers are extended in front of the rack on slides. The anchors must be
able to withstand a force of up to 113 kg (250 lbs.). The user must also
consider the weight of any other device installed in the rack. A crush
hazard exists should the rack tilt forward which could cause serious injury.
Main AC power disconnects: The user is responsible for installing an
AC power disconnect for the entire rack unit. This main disconnect
must be readily accessible, and it must be labeled as controlling power to
the entire unit, not just to the server(s).
Grounding the rack installation: To avoid the potential for an electrical
shock hazard, the user must include a third wire safety-grounding
conductor with the rack installation. If the server power cord is plugged
into an AC outlet that is part of the rack, then the user must provide
proper grounding for the rack itself. If the server power cord is plugged
into a wall AC outlet, the safety-grounding conductor in the power cord
provides proper grounding only for the server. The user must provide
additional, proper grounding for the rack and other devices installed in it.
Intel® SR870BN4 Server System Product Guide 13
