Replacing the Fan Housing
The fan housing resides inside the I/O bay and provides power for the four system cooling fans.
Removing the Fan Housing
To remove the fan housing, loosen the two captive screws (A in Figure 70), and lift the housing out
of the I/O bay as shown.
Intel® SR870BN4 Server System Product Guide
A
Figure 70. Removing the Fan Housing
A
OM12921
195
