minimize, maximize, and close buttons in the upper right corner. The task pane of the help window
can be resized and displays horizontal and vertical scroll bars when necessary.
The information shown in the help window is obtained by running the HTML version of the help
through a translator. Therefore, while the content is the same, the appearance is different because
the local SMU application is not as flexible as a browser.
Most individual screens displayed in the primary information pane have Help buttons. Clicking a
Help button causes the help that is related to that screen to be displayed in the help window, with
the help window appearing in the foreground.
If the Help window is minimized it can only be redisplayed by pressing the <F1> key or clicking a
Help button. If the Help window is not active and the <F1> key is pressed, the About SMU
screen is displayed in the information pane. In general, all keys described in the section on local
SMU keyboard support work for the help window as well as the local SMU application container.

Shutting Down the Server

To shut down the server the user must exit the operating system (if applicable) and then use the
power button to power down the server.
Follow these steps to power down the SR870BN4 server.
1. If the server is running an operating system, use its commands or GUI to logoff (if necessary)
and exit the operating system. If the operating system does not automatically power down the
server, then successfully exiting the operating system causes the following prompt to appear:
Shell>
2. After this prompt appears, press and hold the power button for several seconds. Holding the
power button in powers down the server.
CAUTION
Powering down the server with the power button does not remove all power
from the system. The +12 V standby power is still available to the system
even when it has been powered down. To remove standby power from the
system the user must unplug both power cords from the chassis.

EFI Platform Diagnostic Tests

EFI Platform Diagnostic Tests allow the user to quickly assess the server's hardware status, view
test logs, and determine the server's current configuration. The user can run EFI Platform
Diagnostic Tests from within the EFI environment. The remainder of this section explains how to
run the EFI Platform Diagnostic Tests.

Starting the Application

Use the following steps to setup and run tests.
Intel® SR870BN4 Server System Product Guide 137
