Table 3. Front Panel Control and Indicator Description (continued)
Item Feature
LED Indicators
E System ID (Blinking or
Solid Blue). The system
ID LEDs are located
inside the system ID
switch on the front panel
and on the back panel
F Main Power (Solid or
Blinking Green)
G Power Fault (Solid
Amber)
H Cooling Fault (Solid
Amber)
I General Fault (Solid
amber)
22
Description
Identifies the system. The system ID is activated either by the system
ID switch or through server management software.
Pressing the system ID switch once turns on the LEDs solid blue.
Press the system ID switch again, the solid blue LEDs turn off.
Remove activation - LEDs turn on blinking for 4 minutes (max). The
system ID LEDs cannot be turned off by pressing the switch.
A continuously lit LED indicates the presence of DC power in the
system. The LED goes out when the power is turned off or the power
source is disrupted. Blinking Green indicates the system is in sleep
mode.
Indicates any system power faults. Off indicates power is OK.
Indicates any system cooling faults. Off indicates system cooling is OK.
Indicates a system failure. Off indicates system is OK.
Intel® SR870BN4 Server System Product Guide
