Platform Description
Intel
Local Control Panel
®
Item
Feature
A
LCD display
B
Scroll up button
C
Scroll down button
D
Back button
E
Select button
F
System ID LED (blue)
G
System Power LED (green)
H
System Power button
I
System Status/Fault LED
(green/amber)
J, K
LAN1, LAN2 Status LEDs
(green)
34
A
M L K J I
H
G
F
TP01399
Description
Video display
Press to scroll up on the LCD
Press to scroll down on the LCD
Press to move to the previous LCD screen.
Press to enter a command or select an option on the LCD.
Helps identify the system via server management
Indicates system power status.
Off
Power off
On
Power on
Off
S4 / S5
Blinking
S1
On
S0
Toggles system power
Indicates system status.
Off
Not ready
Green, On
Ready
Green, Blinking
Degraded
Amber, On
Critical Alarm
Amber, Blinking
Non-Critical
Alarm
Indicates LAN activity status.
Off
Idle
On
Inactive
Blinking
Active
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
B
C
D
E
ACPI: No
ACPI: No
ACPI: Yes
ACPI: Yes
Yes
AC power off, POST error
System booted and ready
Processor or DIMM
disabled
Critical power supply,
blower, voltage, or
temperature failure
Redundant power supply
or blower failure.
Non-critical blower,
voltage, or temperature
failure.
No access
Access
