The main window is shown in the following figure.
The Client area of the screen consists of two windows. The first window is the FRU information
window. This window displays the following FRU data in a multi-column format:
Byte number: The bits for the byte are enclosed by the parentheses. For example, bit 5 and bit 4
of byte 7 is represented by 7(5:4)
Field Name
Value
The second window displays the description of attribute names or values you select in the first
window.
The FRU Viewer Utility main window supports the arrow keys, <PgDn>, and <PgUp> to move
around in the display window. It also supports the <F5> key to move forward to the next column
and <F6> to move back to the previous column. Use the <Tab> key to move to the next window in
the client area or to move to the menu. Use <F10> key to move between the client area and the
menu.
124

Figure 52. FRU Viewer Utility Main Window
