NOTE
Additional instructions are available through the SEL Viewer Utility Help
menu.
When you start the SEL Viewer Utility from the graphical user interface (GUI), you will see a
splash screen if the splash screen file is available and in the SEL Viewer Utility search path. No
error message is displayed if the splash screen file is not located.
The splash screen is automatically dismissed after five seconds, or if you press a key.

Graphical User Interface

When the utility is first started, it loads the SEL records from the server. A status box is displayed
to indicate that the SEL Viewer is loading SEL records from the server.
If no SEL entries are found, an information message is provided. Otherwise, after the SEL records
are read from the server, all SEL record information is displayed with one system event on each
line, headed by the Event Description column that contains an interpretation of the event, event
type, and event data.
The SEL Viewer Utility main window is displayed after the splash screen is removed. The data
displays in columns as follows:
A count of the system events being displayed. Starting with number 1, and increasing by one
for each event.
Timestamp.
Sensor type and number.
Event description.
Generator ID.
The SEL Viewer Utility main window supports the arrow keys, <PgDn>, <PgUp>, <Home>, and
<End> to pan across the display window. It also supports the <F5> key to move forward to the next
column and <F6> to move back to the previous column.
116 Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
