5. Open the handle on the replacement fan assembly.
6. Slide the replacement fan into the fan bay. See letter "A" in Figure 62.
7. Push the handle closed until it clicks into place. See letter "B" in the figure
Hot-swapping Hard Disk Drives
The server supports five hot-swap drive carriers. Each carrier holds a standard one-inch high
SCSI-2 or SCSI-3 hard drive.
The procedures in this section describe how to determine drive status, remove a faulty drive, and
install a new drive. If a drive is in a redundant configuration, you can install or replace a hot-swap
hard disk drive without powering down the server.
CAUTION
To ensure proper airflow and server cooling, all drive bays must contain
either a carrier with a hard drive installed in it or a carrier with an air baffle
installed.
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
B
A
Figure 62. System Fan Module Installation
TP01450
139
