Removing and Installing the Processor Air Baffle

You will need to remove the processor air baffle to perform the following procedures:
Removing and installing a processor thermal blank
Removing and installing a processor
Removing and installing a processor cache VRM converter
Removing and installing a CD-ROM/DVD-ROM drive
Removing and installing the main board
Removing and installing a front panel I/O board
Refer to the steps to remove and install the processor air baffle when directed to do so.

Removing the Processor Air Baffle

1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the server and disconnect both AC power cords.
4. Remove the top cover. For instructions, see
5. Disconnect the 100-pin cable from the front panel I/O board. See letter "B" in Figure 85 to
locate the connection point.
6. Hang the end of the cable over the side of the chassis where it will be out of the way.
7. Disconnect the SCSI cable from the SCSI backplane board. See letter "C" in Figure 84 to locate
the cable connection point.
8. Disconnect the CD-ROM/DVD/ROM power cable from the SCSI backplane board. See letter
"D" in Figure 84 to locate the cable connection point.
9. Disconnect any cables attached to the device in the 5 ¼" peripheral bays.
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
"Safety
"Removing the Top Cover".
Information".
171
