Service Technicians Guide
Figure 19 shows the adapter properties and the configuration settings.
The following list shows the available options for each setting category.
<Device Properties>: Takes you to the Device Properties menu shown in Figure 20 on the
following page.
Host SCSI ID: "[0]" to 15]"
SCSI Bus Scan Order: "[Low to High (0..Max)]" or "[High to Low (Max..0)]"
Removable Media Support: "[None]", "[Boot Drive Only]", or "[With Media Installed]"
CHS (Cylinder Head Sector) Mapping: "[SCSI Plug and Play Mapping]" or "[Alternate CHS
Mapping]"
Spin up delay (seconds): "[1]" to "[15]"
Secondary Cluster Server: "[No]" or "[Yes]"
Termination: "[Auto]"
<Restore Defaults>: Allows you to restore the default configuration of the SCSI adapter.
74
Figure 19. Adapter Properties
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
