10. Install the memory board DIMM cover on the memory board:
- Line up the two tabs labeled "A" in Figure 82.
-
Press on the tab labeled "B" in the figure.
A
11. Install the memory board. For instructions, see
Insertion of a Memory
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide

Figure 82. Install Memory Board DIMM cover

Board", depending on your server configuration.
A
"Hot-insertion of a Memory
B
TP01456
Board" or "Cold
163
