Cold Removal of Memory Board

NOTE
If you remove a memory board from your server, either you must replace it
with a replacement memory board or you must install a memory board air
baffle.
1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see
5. Press the latch on the handle (letter "A" in Figure 77) and lift the memory board handle (letter
"B" in Figure 77).
6. Pull up on the memory board handle to lift the memory board from the server. See letter "C" in
Figure 77.
7. Install DIMMs, then reinstall the memory board, or install a memory board air baffle:
- For instructions to install DIMMs, see "Installing and Removing DIMMs".
- For instructions to install the memory board air baffle, see
Board".
8. Install the top cover. For instructions, see

Cold Insertion of a Memory Board

1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see
5. Install DIMMs onto the memory board. For instructions, see
DIMMs".
6. Remove a memory board air baffle from the server. For instructions, see
Memory
Board".
7. Ensure the handle on the memory board is in the open / up position.
8. Align the ends in the card guides and slide the memory board into the memory board slot. See
letter "A" in Figure 78.
9. Push the handle down into the fully-locked position. See letter "B" in Figure 78.
10. Install the top cover. For instructions, see
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
"Removing the Top
Cover".
"Cold Insertion of a Memory
"Installing the Top
Cover".
"Removing the Top
Cover".
"Installing and Removing
"Installing the Top
Cover".
"Safety
Information".
"Safety
Information".
"Cold Removal of
159
