View: The View pull-down menu includes options for viewing / hiding the SEL information
window, Display in Hex/Text, and the screen Resolution. These options are described below.
-
Display In Hex / Display In Text: Under the SEL pull-down menu, you can toggle
between the raw hexadecimal mode display and the interpreted mode display. In the hex
mode display, all of the SEL records are displayed in raw hex format. In interpreted mode
display, all of the SEL records are decoded and displayed in text format. When the display
mode is changed, the SEL Viewer Utility loads or re-loads the SEL entries from the server
and displays the data in the chosen display mode.
The display mode is automatically selected if you read the SEL entries from a file. When
reading SEL entries from a file, the entries are displayed in the mode in which the entries
were saved.
-
Resolution Mode: Two video modes are available. You can toggle between low
resolution at 24 rows by 80 columns and high resolution at 48 rows by 132 columns. High
resolution provides the ability to see more information on a single screen.
Help: The Help menu provides options for General Help and About, as described below.
-
General Help: From the Help pull-down menu, General Help provides information about
how to use the SEL Viewer. The General Help window is divided into two panes. The top
pane lists the main help topics and the bottom pane displays information about the
selected topic. Use the arrow keys to select between topics and use the <F10> or <Tab>
keys to move between panes. To dismiss the help window, press <Esc> key. See the
figure below for the General Help screen.
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
Figure 50. General Help Window
121
