7 Servicing the Processors

®
The Intel Server Platform SR4850HW4 requires a minimum of one 64-bit Intel® Xeon®
processor MP with 1MB L2 Cache or 64-bit Intel® Xeon® processor MP with 8MB L3 Cache. The
following rules must be followed:
Each processor socket must include either a processor thermal blank, or a processor and heat
sink combination.
Processors must be installed in sequential order, beginning with the CPU_1 socket.
If you need to replace a processor:
- Read the information on
- Follow the instructions on
- Follow the instructions on
If you are adding an additional processor:
- Read the information on
- Read the information on
any VRMs.
- Follow the instructions on
- Follow the instructions on
If you are removing a processor, but not installing a replacement processor:
- Read the information on
- Read the information on
remove any VRMs.
- Follow the instructions on
- Follow the instructions on
Handling the Intel® Xeon® Processors
The processors require special handling procedures. Be sure to follow these guidelines when
handling the processors:
Observe the safety precautions, warnings, and cautions described in
Ground yourself with a grounding heel or wrist strap, and an antistatic smock.
Remove processors from the packaging at a clean ESD-protected work surface.
When removing processors from the packaging, keep the package flat on the surface while you
open it so that no processors fall from the packaging.
Hold processors by their sides with the pins facing down.
To avoid mechanical and/or ESD damage, do not touch the cartridge pin array or PCB
components.
When placing processors on the clean ESD-protected work surface, place them with their pins
facing down. Do not stack processors on top of each other.
"Handling the Intel® Xeon®
"Removing a Processor".
"Installing a Processor".
"Handling the Intel® Xeon®
"Processor VRM Requirements" to determine if you need to add
"Processor VRM Requirements".
"Installing a Processor".
"Handling the Intel® Xeon®
"Processor VRM Requirements" to determine if you need to
"Processor VRM Requirements".
"Installing a Processor Thermal
Processors".
Processors".
Processors".
Blank".
"Safety Information".
