9. Connect the SCSI A cable to the main board. For the location of the connection, see Figure 83.
10. Lower the lower center air baffle into place:
Line up the tabs at the sides of the baffle with the slots in the chassis. See letter "B" in
Figure 125.
Line up the two tabs at the bottom of the air baffle with the matching holes. See letter "A"
in the figure.
11. Install the Intel® RAID Activation Key if it is needed. For instructions, see
Intel® RAID Activation
12. Install the RAID DIMM if it is needed. For instructions, see
DIMM".
13. Install the Intel® RAID Smart Battery if it is needed. For instructions, see
RAID Smart Battery".
14. Install the Intel® Management Module. For instructions, see
Management Module (Professional Edition or Advanced
15. Install the Fibre Channel Module if it is needed. For instructions, see
Channel Module".
16. Install the processors. For instructions, see
17. Install the VRMs. For instructions, see
"Removing the Processor Cache VRM
18. Connect the optional external SCSI connector on the back of the chassis if needed. For
instructions, see
19. Install all PCI add-in cards. For instructions, see
20. Install all memory boards and memory board air baffles. For instructions, see
of a Memory Board".
21. Install the processor air baffle. For instructions, see
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide

Figure 125. Installing the Lower Center Air Baffle

Key".
"Installing a Processor Core VRM
Converter".
"Installing the External SCSI Cable
"Installing the RAID DDR2-400
"Installing the Intel®
Edition)".
"Installing a Processor".
Assembly".
"Installing a Non-Hot-plug PCI
"Installing the Processor Air
"Installing the
"Installing the Intel®
"Installing the Fibre
Converter" and
Card".
"Cold Insertion
Baffle".
215
