Main Board

The main board consists of the Intel
connectors, and slots for PCI Express* and PCI-X* adapters. The board also has support for the
®
Intel Management Module – Professional Edition or Intel
Edition, a dedicated Fibre Channel module connector, on-board video, gigabit Ethernet, USB2.0,
Serial-ATA, Ultra320* SCSI, dual flash memory components for BIOS, and RAID On
Motherboard (ROMB).
HH
GG
FF
EE
DD
CC
BB
AA
Item Description
A Generic Communication Module (GCM)
®
B Intel RAID Activation Key
C PCI-X* 100MHz (Slot 7)
D PCI-X* 100MHz (Slot 6)
E PCI Express* x4 – Hot-plug (Slot 5)
F PCI Express* x4 – Hot-plug Plug (Slot 4)
G PCI Express* x4 – Hot-plug (Slot 3)
H PCI-X* 133MHz – Hot-plug (Slot 2)
I PCI Express* x8 – Hot-plug (Slot 1)
J Ethernet LAN 1 (top), LAN 2 (bottom)
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
®
E8500 chipset or Intel®
A B C
CPU 3
Z
Y X
®
E8501 chipset, four memory board
®
Management Module –Advanced
D E F G H I J K
CPU 4 CPU 2 CPU 1
W V U
Item Description
R Memory board Slot B
S DC power connectors
Power distribution board (PDB) signal
T
connector
U Processor socket 1
V Processor socket 2
W Processor socket 4
X VRM 10.2 connector (CPU 4)
Y Processor socket 3
Z SCSI Connector channel A (internal)
AA VRM 9.1 Connector (processor cache)
L
M
N
O
P
Q
R
S
T
