Figure 18. Global Properties List - Intel SR4850HW4 - Server Platform - 0 MB RAM Product Manual

The Global Properties List screen allows you to set the properties for all adapters being controlled.
This screen is shown by the following figure.
The following list shows the available options for each setting option.
Pause when Boot alert Displayed: "[No]" or "[Yes]"
Boot Information Display Mode: "[Verbose]" or "[Terse]"
Negotiate with Devices: "[Supported]" or "[All]"
Video Mode: "[Color]" or "[Monochrome]"
Disable Integrated RAID: "[No]" or "[Yes]"
Support Interrupt: "[Hook Interrupt, The Default]" or "[Bypass Interrupt Hook]"
<Restore Defaults>: Restores the default configuration of the adapters
Press the <Escape> key to exit the Global Properties List and return to the Main menu.
To select the adapter to be configured, use the arrow keys to highlight the adapter then press
<Enter>. The screen clears and the following message is displayed:
Scanning for devices.
If the RAID on Motherboard (ROMB) feature is not enabled, the
following message will be displayed:
Current Firmware does not support IME RAID type. Press
any key to continue.
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide

Figure 18. Global Properties List

NOTE
73
