Feature
Manageability
Front control panel

Platform Front

Item
A CD-ROM / DVD-ROM drive bay
B 5 ¼ peripheral bay
C Video connector
D USB 2.0 ports
E Front control panel. Standard control panel shown.
F Hot-swap fan modules
G Hot-swap disk drives
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
Description
Server Management support through the Intel
Professional Edition or Intel
Remote management
Emergency Management Port (EMP)
Intelligent Platform Management Interface (IPMI) 1.5 compliant, partial
IPMI 2.0 compliance
Wired For Management (WfM) 2.0 compliant
Remote diagnostics support
System power button and LED
System reset button
NMI button
System ID button and LED
Optional LCD
A
G
F
Description

Figure 2. Front Components

®
Management Module –
®
Management Module –Advanced Edition
System status LED
Hard drive status LED
LAN1 and LAN2 status LEDs
Video connector
Three USB 2.0 ports
B C D
F
E
TP01400
31
