8 Servicing the RAID on Motherboard (ROMB)
Components
Installing and Removing the Intel® RAID Activation
Key
Installing the Intel® RAID Activation Key
The optional Intel® RAID Activation Key provides access to the RAID functionality on the main
board.
1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see
5. Remove the memory board air baffle or the memory board from Slot C. For instructions, see
"Cold Removal of Memory
6. If a PCI card is in Slot 7, remove it to expose the Intel® RAID Activation Key holder. For
instructions on removing a PCI card, see
7. Remove the Intel® RAID Activation Key from its package.
"Removing the Top
Board".
"Removing a Non-Hot-Plug PCI
"Safety Information".
Cover".
Card".
