Intel SR4850HW4 - Server Platform - 0 MB RAM Product Manual page 239

Pin Signal
24 DNW_MDIB_DN<2>>
26 DNW_MDIB_DP<3>
19 DNW_MDIB_DN<3>
6 DNW_MDIA_DP<0>
13 DNW_MDIA_DN<0>
11 DNW_MDIA_DP<1>
5 DNW_MDIA_DN<1>
3 DNW_MDIA_DP<2>
10 DNW_MDIA_DN<2>
8 DNW_MDIA_DP<3>
2 DNW_MDIA_DN<3>
Power Signals
4, 7,
9, 12,
14, +1.8V Standby
17,
22, 25
1, 20,
35,
Chassis ground
36,
37, 38
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
Description Dual Stacked Ethernet Connector
positive of differential
pair
Port 1 transceiver 2
negative of differential
pair
Port 1 transceiver 3
positive of differential
pair
Port 1 transceiver 3
negative of differential
pair
Port 2 transceiver 0
positive of differential
pair
Port 2 transceiver 0
negative of differential
pair
Port 2 transceiver 1
positive of differential
pair
Port 2 transceiver 1
negative of differential
pair
Port 2 transceiver 2
positive of differential
pair
Port 2 transceiver 2
negative of differential
pair
Port 2 transceiver 3
positive of differential
pair
Port 2 transceiver 3
negative of differential
pair
Ground
239
