Using the FRU Viewer Utility

Follow these steps to use the FRU Viewer Utility:
1. Boot to the Intel® Server Platforms SR4850HW4 and SR6850HW4 Deployment Toolkit CD.
2. Exit the SCW.
3. Type CD FRUVIEW to change to the FRU Viewer folder.
4. Run the utility by typing the command FRUview
When you start the FRU Viewer Utility from the graphical user interface (GUI), you will see a
splash screen if the splash screen file is available and in the FRU Viewer Utility search path. No
error message is displayed if the splash screen file is not located.
The splash screen is automatically dismissed after five seconds, or if you press a key.

Graphical User Interface (GUI)

When the utility is first started, it loads the FRU records from the server. A status box is displayed
to indicate that the FRU Viewer Utility is loading FRU records from the server.
The FRU Viewer Utility main window is displayed after the splash screen is removed. The FRU
Viewer Utility uses a menu-driven main window. This main window lets you select from four
areas:
Title Bar: The title bar is located at the top of the screen and shows the name and version of
the utility
Menu Area: Provides access to all utility functions and options through three menus: File,
FRU, and Help
Client Area: Displays the FRU information of the selected record in a textual format
Help Tip Area: Displays a brief help message about the selected option
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide 123
