10 Servicing the Intel® Management Module
The Intel® Management connects to the main board. The Intel® Management Module provides
server management firmware and functionality for the system.
NOTES
Do not install the Intel® Management Module or the GCM that is included
with product code AXXIMMADV. The correct Intel® Management Module
product code for the Intel® Server Platform SR4850HW4 and
SR4850HW4/M is AXXIMMADV2.
The GCM features are included in the Intel
and SR4850HW4/M. You do not need to install the GCM. If the wrong
product code is used and you use the GCM that is included with product
code AXXIMMADV, your server will not function correctly.
The first time a server is booted with a new Intel® Management Module
update the BMC with firmware to ensure correct operation.
Installing the Intel® Management Module (Professional Edition or
Advanced Edition)
1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see
5. Remove the memory boards or memory board air baffles from Slots A and B. For instructions,
see "Cold Removal of Memory
6. Remove the Intel® Management Module from the antistatic bag.
®
Server Platform SR4850HW4
"Removing the Top
Board".
"Safety Information".
Cover".
