- Save As: Under the File pull-down menu, Save As provides a way for you to save the
currently displayed FRU to a file. If the save fails because the file cannot be created, the
following message is displayed: "Unable to create save file". If an error occurs while
writing information to the file, the following message is displayed: "Error saving the FRU
data to the file".
The Save As dialog box lets you browse drives and directories for existing files, as shown in
Figure 53. The File Name edit box supports full editing capabilities with the following keys:
<Home>, <End>, Left/Right arrows and <Ins>. The <Ins> key toggles insert and overwrite
editing while in the edit box and this is noted with "INS" or "OVR", displayed in the lower-
right corner of the dialog box.
Exit: From the File pull-down menu, chose Exit to exit the SDR Viewer Utility.
FRU: The FRU pull-down menu includes options for selecting a FRU, viewing FRU
properties, and reloading the FRUs from system. These options are further described below.
-
System FRUs: Under the FRU pull-down menu, System FRUs provides a way to select a
specific FRU entry from the server. This is shown in Figure 54. After you choose a FRU,
the display pane is updated with the selected FRU. By default the first FRU entry is shown
in the display pane when the FRU Viewer Utility is started.
126

Figure 54. FRU Menu
