Hot-swapping Power Supplies

If your server is configured with two power supplies, you can replace a failed or failing power
supply without powering down the server.
CAUTION
Because of chassis airflow disruption, a power supply bay should never be
vacant for more than two minutes when the server power is on. Exceeding
five-minutes might cause the system to exceed the maximum acceptable
temperature and possibly damage system components.

Removing a Power Supply

CAUTION
Any unoccupied power supply slots must be covered with a filler panel.
Uncovered slots can disrupt the airflow used for cooling the system.
1. Observer the safety, ESD, and other precautions described in
2. Remove the AC power cord from the power supply to be removed.
3. Unscrew the thumb latch to unlock the power supply handle. See letter "A" in Figure 68.
4. Open the handle on the power supply. See letter "B" in the figure.
5. Pull the power supply from the chassis and set it on a clean, ESD-protected work surface. See
letter "C" in the figure.
6. Install a replacement power supply or a filler panel. For instructions, see
Supply".
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
A
B

Figure 68. Removing a Power Supply

"Safety Information".
"Installing a Power
C
TP01451
143
