Platform Description

Standard Control Panel

The standard control panel provides a user interface for system management via switches and status
LEDs. The control panel also contains the speaker. Figure 3 shows the location of the buttons and
status LEDs on the standard control panel.
Item
Feature
Front Panel Connectors
A
Video connector
B
Three USB connectors
Front Panel Buttons and LED Indicators
C
Hard Drive Activity LED
(green/amber)
D,
LAN1, LAN2 Status LEDs
E
(green)
32
A
B
I
Video port, standard VGA compatible, 15-pin connector
Three USB 2.0 ports, 4-pin connectors
Indicates hard drive activity and fault status.
LED
Green, On
Green, Blinking
Amber, On
Amber, Slow
Blinking (~1Hz)
Amber, Fast
Blinking (~2.5Hz)
Indicates LAN activity status.
LED
Off
On
Blinking
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
C
D
E
F
G
H
K
J
L
TP01398
Description
State
Description
A hard drive is being
initialized.
A hard drive is active.
Hard drive/slot failure.
A predictive hard
drive/slot failure or
rebuild in process.
Hard drive rebuild
interrupted or rebuild on
empty slot.
State
Description
Idle
Inactive
No Access
Active
Access
