Servicing the Processors

Removing the Processor Core VRM Converters

1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see
5. Remove memory boards or memory board air baffles from Slots C and D. For instructions, see
"Cold Removal of Memory
6. Remove the Fibre Channel Module. For instructions, see
Module"
7. Optional: Remove the center brace. For instructions, see
NOTE
The two-processor core VRM converters are located under the center brace.
You do not need to remove the center brace to remove or install the
processor VRM converters.
8. If you are removing the fourth processor core VRM converter, remove the VRM baffle:
Push down at the top of the baffle to unlatch it. See letter "A" in Figure 100.
Pull the cover out at an angle. See letter "B" in the figure.
188
Board".
A

Figure 100. Removing Processor 4 Core VRM Baffle

Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
"Safety
"Removing the Top Cover".
"Removing the Fibre Channel
"Removing the Center
B
TP01539
Information".
Brace".
