The Device Properties Menu shows options for devices attached to the adapter. It is a large menu
and requires the use of the arrow keys to move fully to the left and fully down to see all
configuration options. Slide bars (not shown above) at the right and on the bottom of the screen
help define your location in the menu. The following list shows the available options for each
setting category:
MB/Sec: "[320]"
MT/Sec: "[0]", "[5]", "[10]", "[20]", "[40]", "[80]" "[160]"
Data Width: "[16]" or "[8]"
Scan ID: "[Yes]" or "[No]"
Scan Luns >0: "[Yes]" or "[No]"
Disconnect: "[On]" or "[Off]"
SCSI Timeout: "[<10>]"
Queue Tags: "[On]" or "[Off]"
<Restore Defaults>: Discards all changes. No warning message is provided before discarding
the changes.
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
Figure 20. Device Properties
75
