Working Inside the System
A
Item Description
A Front panel board connector
B Power distribution board connector
C SCSI cable connector
Item Description
A Control Panel connector
B Main board connector
C SCSI backplane board connector
168
B
E

Figure 84. SCSI Backplane Board Component Locations

A

Figure 85. Front Panel Board Component Locations

Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
F
Item Description
D Power cable connector to CD-ROM/DVD-
ROM drive and 5 ¼" peripheral
E Hot-swap cooling fan connector on
reverse side of board (two)
Hot-swap hard drive sockets on reverse
F
side of board (five)
B
C
TP01449
C
D
E
TP01480
