Configuring Channels; Figure 24. Channels Configuration Screen - Intel SR4850HW4 - Server Platform - 0 MB RAM Product Manual

Configuring Channels

The Channels configuration screen provides a way for you to configure the various channels in the
system. If your server has the Intel
channel and one serial modem channel are supported. If your server has the Intel
Module –Advanced Edition, your server supports one LAN channel, one serial modem channel, and
one advanced LAN channel.
The LAN Channel configuration provides a way to configure the individual LAN channel(s) on the
system. The configuration of each LAN channel is spread across several configuration screens.
Configure LAN Channel 1 on this server: The Configure LAN Channel 1 checkbox allows
you to configure LAN Channel 1. LAN channel 1 is available regardless of the version of the
Intel® Management Module that is installed.
Configure Serial/Modem Channel on this server: The Configure Serial/Modem Channel
checkbox allows you to configure Serial/Modem Channel.
Configure Advanced Intel
Management Module - Advanced Edition LAN Channel checkbox allows user to configure the
Intel® Management Module LAN channel. This option is available only on the Intel
Management Module –Advanced Edition.
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
®
Management Module – Professional Edition, one LAN

Figure 24. Channels Configuration Screen

®
Management Module LAN Channel on this server: The Intel
®
Management
®
®
