Removing the Intel® Management Module
1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see
5. Remove the memory boards from Slots A and B. For instructions, see
Memory Board".
6. Remove the Intel® Management Module. In removing the Module, be sure to hold the module
both by the loop finger grip and by the opposite corner, as shown by the two letters "A" in
Figure 119. Do not twist or bend the Module.
7. Install the memory boards into Slots A and B. For instructions, see
Memory Board".
8. Replace the top cover. For instructions, see
Intel® Server Platforms SR4850HW4 & SR4850HW4/M Product Guide
A
Figure 119. Removing the Intel® Management Module
"Removing the Top Cover".
"Cold Insertion of a
"Installing the Top Cover".
B
A
"Safety Information".
"Cold Removal of
TP01467
209
