Omron SYSMAC CS1D-PD Series Operation Manual page 90

Duplex Unit
Name
CS- 0.3 m
series
0.7 m
Connect-
2 m
ing
Cables
3 m
5 m
10 m
12 m
Long- 0.3 m
distance
0.6 m
Expan-
1 m
sion
Cables
2 m
3 m
5 m
10 m
20 m
30 m
40 m
50 m
2-3 Duplex Unit
2-3-1 Duplex Unit Model
50
Model
CS1W-CN313
CS1W-CN713
CS1W-CN223
CS1W-CN323
CS1W-CN523
CS1W-CN133
CS1W-CN133-B2
CV500-CN312
CV500-CN612
CV500-CN122
CV500-CN222
CV500-CN322
CV500-CN522
CV500-CN132
CV500-CN232
CV500-CN332
CV500-CN432
CV500-CN532
Item
Model number
Number mounted One Duplex Unit is required for a Duplex CPU System.
Weight
One Duplex Unit is required for a Duplex CPU System. It is not required for a
Single CPU System.
Support
Duplex Single
CPU CPU
System System
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Specifications
CS1D-DPL02D (for a Duplex CPU, Dual I/O Expansion System)
CS1D-DPL01 (for a Duplex CPU, Single I/O Expansion System)
200 g max.
Section 2-3
Remarks
Use to connect between Expansion
Racks or between Expansion Rack
and CPU Rack.
Use to connect Long-distance
Expansion Racks.
