Omron SYSMAC CS1D-PD Series Operation Manual page 610

Auxiliary Area Allocations
Addresses Name
Word Bit
A654 to --- Program
A657 File Name
hex
A720 to Power ON
A722 Clock
Data 1
(CS1D-
CPU@@SA
and CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
A723 to Power ON
A725 Clock
Data 2
(CS1D-
CPU@@SA
and CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
A726 to Power ON
A728 Clock
Data 3
(CS1D-
CPU@@SA
and CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
A729 to Power ON
A731 Clock
Data 4
(CS1D-
CPU@@SA
and CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
570
Function
When program replacement starts, the
program file name will be stored in
ASCII. File names can be specified up
to eight characters in length excluding
the extension.
File names are stored in the following
order: A654 to A657 (i.e., from the low-
est word to the highest), and from the
highest byte to the lowest. If a file name
is less than eight characters, the lowest
remaining bytes and the highest
remaining word will be filled with
spaces (20 hex). Null characters and
space characters cannot be used within
file names.
Example: File name is ABC.OBJ
15 0
A654 41 42
A655 43 20
A656 20 20
A657 20 20
This is the history data at Startup Time.
A72000 to A72007: Second (00 to 59)
A72008 to A72015: Minute (00 to 59)
A72100 to A72107: Hour (00 to 23)
A72108 to A72115: Day of month (01 to
31)
A72200 to A72207: Month (01 to 12)
A72208 to A72215: Year (00 to 99)
This is the history data at Startup Time.
A72300 to A72307: Second (00 to 59)
A72308 to A72315: Minute (00 to 59)
A72400 to A72407: Hour (00 to 23)
A72408 to A72415: Day of month (01 to
31)
A72500 to A72507: Month (01 to 12)
A72508 to A72515: Year (00 to 99)
This is the history data at Startup Time.
A72600 to A72607: Second (00 to 59)
A72608 to A72615: Minute (00 to 59)
A72700 to A72707: Hour (00 to 23)
A72708 to A72715: Day of month (01 to
31)
A72800 to A72707: Month (01 to 12)
A72808 to A72815: Year (00 to 99)
This is the history data at Startup Time.
A72900 to A72907: Second (00 to 59)
A72908 to A72915: Minute (00 to 59)
A73000 to A73007: Hour (00 to 23)
A73008 to A73015: Day of month (01 to
31)
A73100 to A73107: Month (01 to 12)
A73108 to A73115: Year (00 to 99)
Settings Status Status at
after startup
mode
change
--- Held Cleared
See at left Held Held
See at left Held Held
See at left Held Held
See at left Held Held
Appendix B
Timing Related
Flags,
Settings
--- ---
When
power is
turned
ON
When
power is
turned
ON
When
power is
turned
ON
When
power is
turned
ON
