Omron SYSMAC CS1D-PD Series Operation Manual page 598

Auxiliary Area Allocations
Address Name
Words Bits
A405 A40515 Peripheral
Servicing
Too Long
Flag (Sin-
gle CPU
Systems
onl7)
A406 All PLC Setup
Error
Location
A407 A40700 Too Many
to I/O Points,
A40712 Details
A40713 Too Many
to I/O Points,
A40715 Cause
A408 A40800 Basic I/O
to Unit Error,
A40807 Slot Num-
ber
A40808 Basic I/O
to Unit Error,
A40815 Rack
Number
A409 A40900 Expan-
to sion I/O
A40907 Rack
Number
Duplica-
tion Flags
558
Function
Turns ON when the peripheral ser-
vicing time in a Parallel Processing
Mode exceeds 2 s. This will also
cause a cycle time error and opera-
tion will stop.
When there is a setting error in the
PLC Setup, the location of that error
is written to A406 in 4-digit hexadec-
imal. The location is given as the
address displayed on a Program-
ming Console.
The CPU Unit will continue operat-
ing and the ERR/ALM indicator on
the front of the CPU Unit will flash.
(A406 will be cleared when the
cause of the error is eliminated.)
When there are too many I/O, CPU
Unit operation will stop, the ERR/
ALM indicator on the front of the
CPU Unit will light, and one of the
following values will be stored here.
The total number of I/O points will be
written here if the capacity of the
CPU Unit is exceeded.
The number of Racks will be written
here when the number of Expansion
I/O Racks exceeds the maximum.
Number of interrupt input points
when there are more than 32 (Single
CPU Systems only)
(These bits will be cleared when the
error is cleared.)
The 3-digit binary value of these bits
indicates the cause of the Too Many
I/O Points Error and shows the
meaning of the value written to bits
A40700 to A40712.
(These bits will be cleared when the
error is cleared.)
When an error has occurred in a
Basic I/O Unit, A40212 will be
turned ON and the slot number
where the error occurred will be writ-
ten here in binary.
(These bits will be cleared when the
error is cleared.)
When an error has occurred in a
Basic I/O Unit, A40212 will be
turned ON and the Rack number
where the error occurred will be writ-
ten here in binary.
The CPU Unit will continue operat-
ing and the ERR/ALM indicator on
the front of the CPU Unit will flash.
(These bits will be cleared when the
error is cleared.)
The corresponding flag will be
turned ON when an Expansion I/O
Rack's starting word address was
set from a Programming Device and
two Racks have overlapping word
allocations or a Rack's starting
address exceeds CIO 0901. Bits 00
to 07 correspond to Racks 0 to 7.
(The corresponding flag will be
cleared when the error is cleared.)
Settings Status
after
mode
change
1: Too long (Par- Cleared
allel processing
cannot be used.)
0: Not too long
(Parallel pro-
cessing can be
used.)
0000 to 01FF Cleared
hex
0000 to 1FFF Cleared
hex
000: Too many Cleared
I/O total
001: Too many
interrupt input
points
101: Too many
Racks
00 to 09 hex Cleared
(Slots 0 to 9)
00 to 07 hex Cleared
(Racks 0 to 7)
ON: Error Cleared
OFF: No error
Appendix B
Status at Timing Related
startup flags,
settings
Cleared Written A268
when
error
occurs
Cleared When A40210
error
occurs
Cleared When A40111,
error A40713
occurs to
A40715
Cleared When ---
error
occurs
Cleared --- A40212
Cleared --- A40212
Cleared --- ---
