Specifications
2-1-2 Duplex Specifications
System Configuration and Basic Functions
Item
Functional The following CPU Units are equivalent in terms of basic functions (I/O points,
equivalence program capacity, DM capacity, and instruction execution speed).
of existing
CS1D-CPU68HA: No equivalent model
CS1-H CPU
CS1D-CPU67HA: Equivalent to CS1H-CPU67H.
Units
CS1D-CPU67SA: Equivalent to CS1H-CPU67H.
CS1D-CPU44SA: Equivalent to CS1G-CPU44H.
CS1D-CPU67H: Equivalent to CS1H-CPU67H.
CS1D-CPU65H: Equivalent to CS1H-CPU65H.
CS1D-CPU42S: Equivalent to CS1G-CPU42H.
CS1D-CPU44S: Equivalent to CS1G-CPU44H.
CS1D-CPU65S: Equivalent to CS1H-CPU65H.
CS1D-CPU67S: Equivalent to CS1H-CPU67H.
The instruction processing speed may vary depending on the model/instruction.
Refer to 9-5 Instruction Execution Times and Number of Steps for details.
Mountable Duplex CPU Systems
Inner Boards Inner Boards cannot be used in a Duplex CPU System except for in the Pro-
cess-control CPU Units (CS1D-CPU
Loop Control Board that cannot be removed.
Single CPU Systems
CS-series Inner Boards can be mounted in CPU Units for Single CPU Systems,
but must be CS1W-LCCB01/05 Loop Control Boards with unit version 1.5 or
later.
Mountable CS-series Basic I/O Units, CS-series Special I/O Units, CS-series CPU Bus
Units Units
C200H Basic I/O Units, C200H Group-2 Multipoint I/O Units, and C200H Special
I/O Units cannot be mounted.
System con- The following system configurations are possible:
figuration
Duplex CPU, Dual I/O Expansion Systems
In a this system, two CS1D CPU Units (CS1D-CPU@@HA/P/H, unit version 1.3
or later), two (or one) CS1D Power Supply Units, and one CS1D-DPL02D
Duplex Unit are mounted to a CS1D-BC042D Backplane.
Duplex CPU, Single I/O Expansion Systems
In a Duplex CPU System, two CS1D CPU Units (CS1D-CPU@@HA/P/H), two
(or one) CS1D Power Supply Units, and one CS1D-DPL01 Duplex Unit are
mounted to a CS1D-BC052 Backplane.
Single CPU Systems
In a Single CPU System, one CS1D CPU Unit (C1D-CPU@@SA/S), two (or one)
CS1D Power Supply Units, and one Duplex Unit are mounted to a CS1D CS1D-
BC082S Backplane.
22
Specifications
@@
P), which have a built-in CS1D-LCB05D
Section 2-1
Reference
3-1-7 Duplex CPU Sys-
tem Restrictions
Appendix E Precau-
tions in Replacing CS1-
H PLCs with CS1D
PLCs
1-2-1 CS1D Duplex
Systems
1-2-1 CS1D Duplex
Systems
1-2 System Configura-
tion
