PLC Setup Coding Sheets for Programming Console
592
221@@@@
Special Peripheral Servicing Unit Numbers (See note.)
Value (hex)
A 00
10 to 1F
20 to 7F
FC
FD
Value (hex)
B 00
10 to 1F
20 to 7F
FC
FD
Note Single CPU Systems only.
222@@@@
Special Peripheral Servicing Unit Numbers (See note.)
A Note used.
Value (hex)
B 00
10 to 1F
20 to 7F
FC
FD
Note Single CPU Systems only.
225@@@@
Value (hex)
A 0000
0001
to
000A
8000
8001
to
800A
Note Single CPU Systems only.
A
B
Special Peripheral Servicing Unit Number
No special servicing
CPU Bus Units 0 to 15 (unit number + 10 hex)
Special I/O Units 0 to 95 (unit number + 20 hex)
RS-232C port
Peripheral port
Special Peripheral Servicing Unit Number
No special servicing
CPU Bus Units 0 to 15 (unit number + 10 hex)
Special I/O Units 0 to 95 (unit number + 20 hex)
RS-232C port
Peripheral port
A
B
Special Peripheral Servicing Unit Number
No special servicing
CPU Bus Units 0 to 15 (unit number + 10 hex)
Special I/O Units 0 to 95 (unit number + 20 hex)
RS-232C port
Peripheral port
A
Power-OFF Power OFF Detection Delay Time
Interrupt Task
Disabled 0 ms
1 ms
to
10 ms
Enabled 0 ms
1 ms
to
10 ms
