Omron SYSMAC CS1D-PD Series Operation Manual page 538

Specifications of Basic I/O Units and High-density I/O Units
CS1W-OD211 Transistor Output Unit (16 Points, Sinking)
Rated Voltage
Operating Load Voltage
Range
Maximum Load Current
Maximum Inrush Current
Leakage Current
Residual Voltage
ON Response Time
OFF Response Time
Insulation Resistance
Dielectric Strength
No. of Circuits
Internal Current Consumption 5 V DC 170 mA max.
Fuses
External Power Supply
Weight
Circuit Configuration
Terminal Connections
Note Terminal numbers A0 to A9 and B0 to B9 are used in this manual, but they are not printed on the Unit.
498
12 to 24 V DC
10.2 to 26.4 V DC
0.5 A/point, 4.0 A/common, 8.0 A/Unit
4.0 A/point, 10 ms max.
0.1 mA max.
1.5 V max.
0.5 ms max.
1.0 ms max.
20 MΩ between the external terminals and the GR terminal (100 V DC)
1,000 V AC between the external terminals and the GR terminal for 1 minute at a leakage
current of 10 mA max.
16 (8 points/common, 2 circuits)
None
10.2 to 26.4 V DC, 20 mA max.
270 g max.
Output indicator
0
A0
L
B0
2
A1
L
B1
12 to 24 VDC
4
A2
L
B2
6
A3
L
B3
COM0
A4
B4
8
A5
L
B5
10
A6
L
B6
12
12 to 24 VDC
A7
L
B7
14
A8
L
B8
COM1
A9
B9
• When wiring, pay careful attention to the polarity.
• The load may operate incorrectly if the polarity is reversed.
+V
OUT00
to
OUT07
COM0
+V
OUT00
to
OUT07
COM1
1
L
3
L
5
L
7
L
+V
9
L
11
L
13
L
15
L
+V
Appendix A
