Auxiliary Area Allocations
Addresses Name
Word Bit
A530 A53000 Power
to Interrup-
A53015 tion Dis-
able
Setting
A580 A58000 FB Com-
to munica-
(See
A58003 tions
note.)
Instruc-
tion
Retries
(Unit ver-
sion 4.0 or
later)
A581 FB Com-
munica-
(See
tions
note.)
Instruc-
tion
Response
Monitor-
ing Time
(Unit ver-
sion 4.0 or
later)
A582 FB
DeviceNet
(See
Communi-
note.)
cations
Instruc-
tion
Response
Monitor-
ing Time
(Unit ver-
sion 4.0 or
later)
A595 --- IR00 Out-
and put for
A596 Back-
ground
Execution
(Single
CPU Sys-
tems only)
A597 --- DR00
Output for
Back-
ground
Execution
(Single
CPU Sys-
tems only)
Note: These Auxiliary Area bits/words are not to be written by the user. The number of resends and response monitoring time must be set
by the user in the FB communications instructions settings in the PLC Setup, particularly when using function blocks from the
OMRON FB Library to execute FINS messages or DeviceNet explicit messages communications. The values set in the Settings for
OMRON FB Library in the PLC Setup will be automatically stored in the related Auxiliary Area words A580 to A582 and used by the
function blocks from the OMRON FB Library.
566
Function
Set to A5A5 hex to disable power inter-
rupts between DI(693) and EI(694)
instructions.
Supported for Single CPU Systems
only when the power OFF interrupt task
is disabled.
Automatically stores the number of
retries in the FB communications
instruction settings specified in the PLC
Setup.
Automatically stores the FB communi-
cations instruction response monitor-
ing time set in the PLC Setup.
Automatically stores the FB DeviceNet
communications instruction response
monitoring time set in the PLC Setup.
When an index register is specified as
the output for an instruction processed
in the background, A595 and A596
receive the output instead of IR00.
When a data register is specified as the
output for an instruction processed in
the background, A597 receives the out-
put instead of DR00.
Settings Status Status at
after startup
mode
change
A5A5 hex: Cleared Cleared
Masking power
interruption
processing
enabled
Other: Mask-
ing power inter-
ruption
processing not
enabled.
0 to F hex As set in Cleared
PLC
Setup
0001 to FFFF As set in Cleared
hex (Unit: 0.1 PLC
s; Range: 0.1 Setup
to 6553.5)
0000 hex: 2 s
0001 to FFFF As set in Cleared
hex (Unit: 0.1 PLC
s; Range: 0.1 Setup
to 6553.5)
0000 hex: 2 s
0000 0000 to Cleared Cleared
FFFF FFFF
hex
(A596 contains
the leftmost
digits.)
0000 to FFFF Cleared Cleared
hex
Appendix B
Timing Related
Flags,
Settings
--- ---
Written at
start of
operation
--- ---
--- ---
