Configuration Devices
Rack Configurations
Note
36
Rack name
CPU Rack for CPU Units for Duplex CPU Sys-
Duplex CPU, Dual tems (unit version 1.3 or later)
I/O Expansion Sys- (See note 1.)
tems
CS1D Power Supply Units
CPU Backplane for Duplex CPU
Systems (See note 2.)
Duplex Unit (See note 2.)
CS1D I/O Control Units (See
note 2.)
Memory Card
CPU Rack for CPU Units for Duplex CPU Sys-
Duplex CPU, Single tems (See note 1.)
I/O Expansion Sys-
CS1D Power Supply Units
tems
CPU Backplane for Duplex CPU
Systems (See note 3.)
Duplex Unit (See note 3.)
Memory Card
CPU Rack for Sin- CPU Unit for Single CPU Sys-
gle CPU Systems tems (See note 4.)
CS1D Power Supply Units
CPU Backplane for Single CPU
Systems (See note 4.)
Duplex Inner Boards
Memory Card
1. The CPU Units for Duplex CPU Systems are specially designed for use in
Duplex CPU Systems and cannot be used in Single CPU Systems or
mounted in a CS-series CPU Rack.
2. The CS1D-BC042D CPU Backplane, CS1D-DPL02D Duplex Unit, and
CS1D I/O Control Unit are specially designed for use in Duplex CPU Dual
I/O Expansion Systems. These components cannot be used in Duplex
CPU Single I/O Expansion Systems, Single CPU Systems, or a CS-series
CPU Rack.
3. The CS1D-BC052 CPU Backplane and CS1D-DPL01 Duplex Unit are
specially designed for use in Duplex CPU Single I/O Expansion Systems.
These components cannot be used in Duplex CPU Dual I/O Expansion
Systems, Single CPU Systems, or a CS-series CPU Rack.
4. CPU Units for Single CPU Systems and CPU Backplanes for Single CPU
Systems are specially designed for use in Single CPU Systems and cannot
be used in Duplex CPU Systems or for a CS-series CPU Rack.
Devices
Two Units (or one) are
required.
Two Units (or one) are
required.
One Unit is required.
One Unit is required.
Two Units (or one) are
required for expansion.
Install a Memory Card in the
active CPU Unit as required.
Two Units (or one) are
required.
Two Units (or one) are
required.
One Unit is required.
One Unit is required.
Install a Memory Card in the
active CPU Unit as required.
One Unit is required.
Two Units (or one) are
required.
One Unit is required.
Install an Inner Board as
required.
Install a Memory Card as
required.
Section 2-2
Remarks
