Omron SYSMAC CS1D-PD Series Operation Manual page 119

Programming Devices
CX-Programmer Connecting Cables
Unit Unit port
CPU Units Peripheral
port
Built-in RS-
232C port
D-Sub, 9-pin,
female
Serial Com- RS-232C
munications Port
Boards/Units
D-Sub, 9-pin,
(See note 1.)
female
Note
RS-232C Cables for a Peripheral Port
Unit Unit port
CPU Units Built-in
periph-
eral port
Using a CQM1-CIF01/02 Cable for a Peripheral Port
Unit Unit port
CPU Units Built-in
periph-
eral port
2. If cables with model numbers ending in -V instead of -CV are used to con-
nect the computer running the CX-Programmer to the RS-232C port (in-
cluding when using a CS1W-CN118 Cable), a peripheral bus connection
cannot be used. Use a Host Link (SYSWAY) connection. To connect to the
port using a peripheral bus connection, prepare an RS-232C cable as de-
scribed in Connection Methods on page 81.
Computer Computer
port
IBM PC/AT or D-Sub, 9-
compatible pin, male
IBM PC/AT or D-Sub, 9-
compatible pin, male
IBM PC/AT or D-Sub, 9-
compatible pin, male
1. Serial Communications Boards are supported only for Single CPU Sys-
tems.
2. Before connecting a connector from the above table to a PLC RS-232C
port, touch a grounded metal object to discharge static electricity from your
body. The XW2Z-@@@S-CV Cables have been strengthened against stat-
ic because they use a static-resistant connector hood (XM2S-0911-E).
Even so, always discharge static electricity before touching the connec-
tors.
3. Do not use commercially available RS-232C personal computer cables.
Always use the special cables listed in this manual or make cables accord-
ing to manual specifications. Using commercially available cables may
damage the external devices or CPU Unit.
Computer Computer
port
IBM PC/AT D-Sub, 9-
or compatible pin, male
Computer Computer
port
IBM PC/AT or D-Sub, 9-
compatible pin, male
Serial
communications
mode
Peripheral bus or CS1W-CN226
Host Link
CS1W-CN626
Peripheral bus or XW2Z-200S-CV 2 m
Host Link
XW2Z-500S-CV 5 m
Host Link XW2Z-200S-CV 2 m
XW2Z-500S-CV 5 m
Serial Model
communications
mode
Peripheral bus or CS1W-CN118 +
Host Link XW2Z-200S-
CV/500S-CV
Serial Model
communications
mode
Host Link CS1W-CN114
+ CQM1-CIF02
Section 2-6
Model Length Cable notes
2.0 m ---
6.0 m
Use a static-
resistant con-
nector.
Use a static-
resistant con-
nector.
Length Cable notes
0.1 m+ XW2Z-@@@S-
(2 m or CV models
5 m) use a static -
resistant con-
nector.
Length Cable notes
0.05 m + ---
3.3 m
79
