Omron SYSMAC CS1D-PD Series Operation Manual page 565

Auxiliary Area Allocations
Address Name
Words Bits
A020 to Previous Cause of Switching to Simplex Operation (Duplex CPU Systems only)
A022
--- Time of
Previous
Switch
A02000
from
to
Duplex to
A02007
Simplex
Operation
A02008
to
A02015
A02100
to
A02107
A02108
to
A02115
A02200
to
A02207
A02208
to
A02215
A023 Current Cause of Switching to Simplex Operation (Duplex CPU Systems only)
(Check in new active CPU Unit after switch to simplex operation.)
A02300 Duplex
Verifica-
tion Error
Switch
Flag
A02301 Duplex
Bus Error
Switch
Flag
A02302 Duplex Ini-
tialization
Error
Switch
Flag
A02303 CPU Unit
Setting
Switch
Flag
A02304 CPU Error
(WDT)
Switch
Flag
A02306 FALS
Instruc-
tion Error
Switch
Flag
Function
The time of the previous switch from
duplex to simplex operation is stored.
Seconds (00 to 59)
Minutes (00 to 59)
Hours (00 to 23)
Day of month (01 to 31)
Month (01 to 12)
Year (00 to 99)
ON: A duplex verification error caused a
switch from duplex to simplex operation.
Only operation is switched and the active
CPU Unit will not be switched.
This flag is turned OFF when duplex oper-
ation is restored.
ON: A duplex bus error caused a switch
from duplex to simplex operation. Only
operation is switched and the active CPU
Unit will not be switched.
This flag is turned OFF when duplex oper-
ation is restored.
ON: An error during duplex initialization
caused a switch from duplex to simplex
operation and duplex operation was never
started. The active CPU Unit will not be
switched.
This flag is turned OFF when duplex oper-
ation is restored.
ON: Changing the CPU Unit's switch from
USE to NO USE caused a switch from
duplex to simplex operation. The active
CPU Unit will be switched.
This flag is turned OFF when duplex oper-
ation is restored.
ON: A CPU Unit error (WDT) caused a
switch from duplex to simplex operation.
The active CPU Unit will be switched.
This flag is turned OFF when duplex oper-
ation is restored.
ON: Execution of an FALS instruction
caused a switch from duplex to simplex
operation. The active CPU Unit will be
switched.
This flag is turned OFF when duplex oper-
ation is restored.
Settings Status Status
after
mode startup
change
--- Held Held
ON: Switched to Held Held
simplex opera-
tion for duplex
verification error
OFF: Normal
ON: Switched to
simplex opera-
tion for duplex
bus error
OFF: Normal
ON: Switched to
simplex opera-
tion for duplex
initialization
error
OFF: Normal
ON: Switched to
simplex opera-
tion for CPU set-
ting
OFF: Normal
ON: Switched to
simplex opera-
tion for CPU
error
OFF: Normal
ON: Switched to
simplex opera-
tion for FALS
instruction
OFF: Normal
Appendix B
Timing Related
at flags,
settings
Data from ---
A024 to
A026 is
stored
when
duplex
operation
is recov-
ered.
When A31600
operation in active
is and
switched standby
from CPU
duplex to Units
simplex
A31601
operation
in active
and
standby
CPU
Units
---
---
---
A40106
in CPU
Unit with
error
525
